Feeder Pillar
Feeder Pillar
An extensive range of low voltage feeder pillars from the transformer to the end distribution, providing solutions from fuse protection to the latest circuit breaker technology. The assemblies are purely custom built to meet customer specific needs. Feeder Pillar can be installed outdoors or indoors, in a public or private network to protect and provide bulk distribution of electricity to residential & commercial complexes.
- type tested as per IEC 60439-1 at CPRI
- System-415/440V, 3 phase, 4wire
- Highest current rating available: 2400A.
- Increased Degree of protection up to IP-55 to provide maximum protection in outdoor installation.
- Short circuit withstand strength up to 50kA for 1 sec.
- Wide choice for selection of enclosure material as CRCA/GP Sheet.
- All live exposed parts screened - greatly reduce the risk of electrical shock during service conditions.
- Available with wide range of accessories as per customer requirement as MDI, MFM, KWH, Voltmeters, Cable clamps & pad locking etc.
Application -
Used by Govt Infra, Utilities (Electricity Board) for power distribution in housing, commercial and industrial complex.
Din Type Feeder Pillar
This range goes one step further with advanced Vertical fuse rail & fuse switch (up to 630A) to utilize the blade(DIN) type fuse in outgoing feeders. Also available with conventional Fuse Base type.
Wedge Type Feeder Pillar
Catering to the specific requirements of some regions, which offers a wide range of Wedge type feeder pillars with Vertical fuse rail (up to 630A) suitable for accommodating Wedge type fuses in outgoing feeders.
Other Ranges
Incomer Options: SD/SDF, MCCB, ACB Outgoing Options: SDF, MCCB, various type of cutouts such as House Service Cutouts/Heavy Duty Cutouts
